5 Ton Adjustable Boiler Cylinder Welding Rotator | Light Duty Tank Turning Rolls

  • 1
  • 2
  • 3

Supply Ability : 500 units/month

Single Drive Motor Power : 1.5kw

Model Number : KTG-05

Rotaion Speed : 0.1-1rpm

MOQ : 1

Delivery Time : 10-20 work days

Rated Load Capacity : 5000kg (5 Ton)

Applicable Workpiece Outer Diameter : φ300-φ2800mm

Payment Terms : L/C,D/A,D/P,T/T,

Driving Form : Dual Motor Dual Drive

Price : 500-1000USD

Roller Center Distance : Manually Adjustable

Certification : CE

Voltage : 380V

Brand Name : LEMAR

Model NO. : KTG-05

Place of Origin : WUXI

Welding Turning Rolls : Type Adjustable

Packaging Details : 220.00cm * 120.00cm * 130.00cm

Contact Now

5 Ton Adjustable Boiler Cylinder Welding Rotator | Light Duty Tank Turning Rolls
5 Ton Adjustable Boiler Cylinder Welding Rotator | Light Duty Tank Turning Rolls
Product Overview

The 5 Ton Adjustable Boiler Cylinder Welding Rotator is a compact and cost-effective welding auxiliary machine, specially designed for small boiler shells, thin-wall pipes, material hoppers and mini storage tanks. Featuring manual screw adjustable span and low-vibration synchronous rotation, it ensures stable and uniform girth welding, greatly improving welding efficiency and reducing rework rate for small and medium metal fabrication workshops.

5 Ton Adjustable Boiler Cylinder Welding Rotator | Light Duty Tank Turning Rolls 5 Ton Adjustable Boiler Cylinder Welding Rotator | Light Duty Tank Turning Rolls
Technical Parameters
Model HGK-5 Adjustable Welding Rotator
Rated Load 5 Ton (5000kg)
Applicable Diameter 250mm - 2800mm
Rotation Speed 0.3-3 r/min stepless speed
Standard Roller Wear-resistant PU composite roller
Adjustment Method Manual screw adjustable span
Control Mode Wired + wireless dual control
Custom Voltage 380V/415V/460V 50/60Hz
Certification CE, ISO9001
Core Features
  • Adjustable Roller Span – Manual screw adjustment flexibly fits cylinder diameters from 250mm to 2800mm, supporting mixed-size batch production.
  • Anti-scratch PU Roller – Standard high-elastic PU rollers protect stainless steel, painted and polished workpiece surfaces without indentation or scratches.
  • Stable Synchronous Rotation – Dual-motor synchronous drive ensures low-vibration steady operation for smooth and consistent girth welds.
  • Stepless Frequency Speed Control – 0.3-3r/min adjustable speed perfectly matches thin-wall and medium-wall cylinder welding requirements.
  • Dual Control System – Equipped with wired control box and wireless remote controller for flexible and convenient on-site operation.
  • Global Safety Standard – Built-in overload and emergency stop protection, CE & ISO certified with customizable global industrial voltage.
5 Ton Adjustable Boiler Cylinder Welding Rotator | Light Duty Tank Turning Rolls 5 Ton Adjustable Boiler Cylinder Welding Rotator | Light Duty Tank Turning Rolls
Standard & Optional Accessories
Standard Accessories
  • PU driving & driven roller set
  • Frequency conversion control box & wireless remote
  • Manual screw adjustment mechanism
  • Overload & emergency stop safety device
  • Complete installation bolts and cables
  • English manual and factory test report
Optional Upgraded Accessories
  • Solid steel / alloy steel rollers
  • Hands-free foot switch
  • Anti-drift limiting baffle
  • High temperature resistant rollers
  • Extended base frame for long cylinders
  • Welding grounding conductive device
5 Ton Adjustable Boiler Cylinder Welding Rotator | Light Duty Tank Turning Rolls 5 Ton Adjustable Boiler Cylinder Welding Rotator | Light Duty Tank Turning Rolls
Application Scope
  • Small hot water boiler cylinder girth welding
  • Thin-wall pipe and heat exchanger tube processing
  • Mini pressure vessel and stainless steel tank fabrication
  • Cylindrical workpiece polishing and flaw detection
5 Ton Adjustable Boiler Cylinder Welding Rotator | Light Duty Tank Turning Rolls5 Ton Adjustable Boiler Cylinder Welding Rotator | Light Duty Tank Turning Rolls
Frequently Asked Questions
Q: What cylinder sizes does the 5 ton rotator support?
A: It adapts cylinder diameters from 250mm to 2800mm, suitable for small boilers and tanks.
Q: Will PU rollers damage stainless steel surfaces?
A: No, high-elastic PU rollers protect polished and painted workpieces without scratches.
Q: Is the rotation speed adjustable?
A: Yes, 0.3-3r/min stepless speed regulation for different welding processes.
Q: Can you customize local industrial voltage?
A: Global voltage customization (380V/415V/460V) is fully supported.
Q: Does it support wireless operation?
A: Equipped with wireless remote control for flexible field operation.
Tip: Share your workpiece diameter, weight and local voltage, we will provide the most matching rotator configuration and exact quotation immediately.
